Product Overview

The Haiwang ZKJ-D Stack Sizer is a wet fine particle screening equipment developed by Haiwang through the introduction of advanced foreign technology. It adopts an advanced stack design, allowing for 5 parallel feeding routes, occupying a small footprint, and offering high processing capacity. Equipped with original imported vibration motors, an internationally advanced linear motion trajectory, a screen inclination angle of 15-25 degrees, and repeat pulping technology, this equipment ensures fast material transfer speed and high screening efficiency. The screen frame is supported by original imported spring suspension, resulting in low noise, low power consumption, and minimal equipment load, contributing to a long service life. It utilizes original imported flexible polyurethane anti-clogging screens (with screen openings as fine as 0.074mm), providing high efficiency, high open area, anti-clogging, wear resistance, and an extended service life.

Specification

ZKJ1007 standard technical parameters

Technical Parameters of ZKJ1208 Three-Stage Type

Technical Parameters of ZKJ1408

Technical Parameters of ZKJ1408 Three-Stage Type

Technical Parameters of ZKJ Dual-Channel Single-Layer

Technical Features

• High-efficiency drum-type vibration motor with IP66 protection rating.
• Suspended anti-shear support springs with low noise and long service life.
• Flexible polyurethane screen mesh with an open area of up to 35-45%, screening efficiency of 75-90%, and a service life exceeding 6 months. It features high screening efficiency, anti-clogging, and wear resistance.
• Secondary pulping tank that fully flips materials, reducing the feed concentration on the second screen surface and improving classification efficiency.
• Matrix patented structure cloth dispenser to evenly distribute the slurry across the entire screen width.
• The screener is manufactured using high-quality alloy steel Q355B.
• All flow parts undergo wear-resistant treatment, such as slurry distributor, upper and lower screen funnels, and wear-resistant lining materials inside the cloth dispenser.
• The screen is integrally formed with a built-in high-strength fiber framework.
• Introduction of nano-modified polyurethane to enhance the aging resistance of the screen, with a service life of no less than 6 months.
• Hooked edge design for easy removal and installation of the screen.
• Fully enclosed structure for the vibration motor with IP66 protection rating.
• Compact size, light weight, and high vibration force for the vibration motor, ensuring stable and reliable operation.
• Anti-shear rubber springs with low noise, good vibration isolation effect, and almost no vibration in the support.

Application

Used in closed-circuit grinding and grading processes in iron ore, lead-zinc ore, tin ore, tungsten ore, and other black and non-ferrous metal ore dressing plants.

Employed in coal preparation plants for the separation and classification of coarse coal slurry, in combination with cyclones, FBS™ coarse coal slurry compound fluidized bed separators, or LXA coal spiral separators.

Applied in non-metallic ore dressing plants such as feldspar, quartz, kaolin, etc., for processes such as classification and desilting.
